Photovoltaic panel Canadian Solar CS7N-660MS | 660W | HiKu7 Mono PERC | 132 Cells | 21.4% Efficiency | 12/30 years warranty

SKU: CS7N-660MS Category: Tag:

90,00   /  201.37 BGN

Availability: In Stock

Technical characteristics:

Model: CS7N-660MS
Cell type: Monocrystalline PERC, 132 half-cell
Rated Power (STC): 660 W
Modular efficiency: 21.4%
Dimensions: 2384 × 1305 × 35 mm
Weight: 34.4 kg
Max. System Voltage: 1500 V DC
Operating temperature: -40°C to +85°C
Pmax temperature coefficient: -0.34%/°C
Max. Mechanical load: 5400 Pa (snow) / 2400 Pa (wind)
Application Class: Class A
Tolerance: 0~+5W
Frame: Anodized Aluminum
Coating: Tempered anti-reflective glass 3.2 mm
Connectors: T4, MC4, PV-KST4-EVO2 (IEC)
Junction Box: IP68, with 3 bypass diodes
Cable length: 460 mm (+) / 340 mm (–)

In stock

SKU: CS7N-660MS Category: Tag:
  • Description
  • Additional information
  • Documentation

Description

The Canadian Solar CS7N-660MS is a powerful monocrystalline solar panel, part of the HiKu7 industrial series, optimized for large-scale high-efficiency solar projects. With a rated power of 660W and 132 half-cut PERC cell technology, it provides low losses, stable operation at high temperatures, and excellent mechanical resistance.

Key advantages:

Low LCOE – lower system costs and better returns
Reduced shading losses and resistive effects (thanks to half-cut cells)
Lower hotspot temperature – extended service life
Compatible with 1500V systems – fewer strings, lower BOS consumption
Optimised for vertical and horizontal mounting

Guarantee:

  • 12 Years Product Warranty

  • 30 Years Linear Performance Warranty
    ➤ Residual power ≥ 87.4% at the 30th year

The CS7N-660MS is an excellent solution for industrial and commercial solar projects where the optimal balance between high power, efficiency and reliability is sought.

  • We inform you that despite our efforts, we cannot guarantee that the published information and photos do not contain inaccuracies or errors that cannot be a legal basis for claims.

Additional information

Weight 36 kg
Dimensions 2384 × 1303 × 35 cm
construction

Monocrystalline panels

Frame color

Gray frame

Warranty

12

Cell performance guarantee

Power

Power W

Single-sided / Double-sided

one-faced

Documentation

PDF link



Description

The Canadian Solar CS7N-660MS is a powerful monocrystalline solar panel, part of the HiKu7 industrial series, optimized for large-scale high-efficiency solar projects. With a rated power of 660W and 132 half-cut PERC cell technology, it provides low losses, stable operation at high temperatures, and excellent mechanical resistance.

Key advantages:

Low LCOE – lower system costs and better returns
Reduced shading losses and resistive effects (thanks to half-cut cells)
Lower hotspot temperature – extended service life
Compatible with 1500V systems – fewer strings, lower BOS consumption
Optimised for vertical and horizontal mounting

Guarantee:

  • 12 Years Product Warranty

  • 30 Years Linear Performance Warranty
    ➤ Residual power ≥ 87.4% at the 30th year

The CS7N-660MS is an excellent solution for industrial and commercial solar projects where the optimal balance between high power, efficiency and reliability is sought.

  • We inform you that despite our efforts, we cannot guarantee that the published information and photos do not contain inaccuracies or errors that cannot be a legal basis for claims.

Additional information

Weight 36 kg
Dimensions 2384 × 1303 × 35 cm
construction

Monocrystalline panels

Frame color

Gray frame

Warranty

12

Cell performance guarantee

Power

Power W

Single-sided / Double-sided

one-faced

Documentation

PDF link
