Hybrid Single Phase Inverter Deye SUN-12K-SG02LP1-EU-AM3 For 48V Batteries – 10 Years Warranty
2089,32 € / 0.00 BGN
Availability: Contact us
Technical characteristics:
✅ Type: Hybrid (grid + battery)
✅ Rated Power (AC): 12.0 kW
✅ Phase: Single-phase (1Ph)
✅ Number of MPPT trackers: 2
✅ Maximum PV input power: 15.6 kW
✅ Maximum PV input voltage: 500 V
✅ MPPT operating range: 120 – 500 V
✅ Maximum current from PV string: 2 × 16 A
✅ Battery type: Low-voltage (48V) Li-ion or lead-acid
✅ Battery voltage range: 40 – 60 V
✅ Maximum Charge/Discharge Current: 190 A
✅ UPS function (EPS mode): Yes, switching time below 10 ms
✅ Maximum efficiency: up to 97.6%
✅ Euro efficiency: 97.0%
✅ MPPT Efficiency: >99%
✅ Degree of protection: IP65 – for outdoor and indoor installation
✅ Operating temperature: -25°C to +60°C
✅ Communication: RS485, CAN, built-in Wi-Fi, LAN (4G option)
✅ Dimensions (W x H x D): approx. 540 × 670 × 220 mm
✅ Weight: ~39 kg
✅ Warranty: 10 years
Out of stock
-
Description
-
Additional information
-
Documentation
Description
The SUN-12K-SG02LP1-EU-AM3 is a high-efficiency single-phase hybrid inverter built for large residential and small business solar systems. The inverter combines solar generation, battery storage with low-voltage 48V batteries and emergency power supply (EPS mode). Ideal for customers looking for maximum self-consumption, energy independence and optimization of electricity costs.
Compatible batteries:
-
Working with 48V batteries – a safe and easy-to-install solution
-
Two MPPT trackers – maximum optimization of yield from differently oriented panels
-
EPS mode (emergency power supply) – provides power for critical loads when the grid is shut down
-
Smart remote control and monitoring – via SolisCloud and mobile app
-
Advanced protection: anti-islanding, over-voltage, over-temperature and shock protection
-
AC Coupling – possibility of integration with a diesel generator or an existing system
Applications:
-
Large Single Phase Residential Solar Systems
-
Villas, farms, small businesses
-
Self-consumption systems with battery storage
-
Installations in remote areas with the need for backup power
The SUN-12K-SG02LP1-EU-AM3 combines high power, intelligent control and maximum flexibility for optimal use of solar energy.
We inform you that despite our efforts, we cannot guarantee that the published information and photos do not contain inaccuracies or errors that cannot be a legal basis for claims.
Description
Description
The SUN-12K-SG02LP1-EU-AM3 is a high-efficiency single-phase hybrid inverter built for large residential and small business solar systems. The inverter combines solar generation, battery storage with low-voltage 48V batteries and emergency power supply (EPS mode). Ideal for customers looking for maximum self-consumption, energy independence and optimization of electricity costs.
Compatible batteries:
-
Working with 48V batteries – a safe and easy-to-install solution
-
Two MPPT trackers – maximum optimization of yield from differently oriented panels
-
EPS mode (emergency power supply) – provides power for critical loads when the grid is shut down
-
Smart remote control and monitoring – via SolisCloud and mobile app
-
Advanced protection: anti-islanding, over-voltage, over-temperature and shock protection
-
AC Coupling – possibility of integration with a diesel generator or an existing system
Applications:
-
Large Single Phase Residential Solar Systems
-
Villas, farms, small businesses
-
Self-consumption systems with battery storage
-
Installations in remote areas with the need for backup power
The SUN-12K-SG02LP1-EU-AM3 combines high power, intelligent control and maximum flexibility for optimal use of solar energy.
We inform you that despite our efforts, we cannot guarantee that the published information and photos do not contain inaccuracies or errors that cannot be a legal basis for claims.
